Load Balancing Azure Container Instances with Envoy

Azure Container Instances are a very convenient and easy-to-use but do have limitations that, sometimes, make them unsuitable for some scenarios. One of those limitations, at least at the writing of this article, is the inability to use an Azure Load Balancer with containers deployed to a private network (public containers can be load distributed with an Azure Traffic Manager).

The Alternative — Envoy

To overcome the Azure Load Balancer’s limitation work with Azure Container Instances, an additional container running Envoy can be used to distribute the load between the other backend containers, and this is exactly what this article will be showing.

The Example

The complete Terraform based example, which deploys three backend containers, one Envoy container and an Azure Firewall, can be found in this GitHub repository:

GitHub - ItayPodhajcer/envoy-load-balance-aci

Contribute to ItayPodhajcer/envoy-load-balance-aci development by creating an account on GitHub.

For brevity, I will only cover the areas of the example that specifically handle the creation and configuration of the Envoy container, starting with the template file for Envoy’s configuration. The configuration will define an HTTP listener that routes to a cluster that uses a private DNS record to pull the list of nodes:

static_resources:

  listeners:
  - address:
      socket_address:
        address: 0.0.0.0
        port_value: ${port}
    filter_chains:
    - filters:
      - name: envoy.filters.network.http_connection_manager
        typed_config:
          "@type": type.googleapis.com/envoy.extensions.filters.network.http_connection_manager.v3.HttpConnectionManager
          stat_prefix: ingress_lbaci
          codec_type: AUTO
          route_config:
            name: lb_route
            virtual_hosts:
            - name: lb_service
              domains: ["*"]
              routes:
              - match: { prefix: "/" }
                route: { cluster: lbaci }
          http_filters:
          - name: envoy.filters.http.router

  clusters:
  - name: lbaci
    connect_timeout: 0.25s
    type: STRICT_DNS
    lb_policy: ROUND_ROBIN
    load_assignment:
      cluster_name: lbaci
      endpoints:
      - lb_endpoints:
        - endpoint:
            address:
              socket_address:
                address: ${host_record}
                port_value: ${port}

Next, a Terraform module that uses that template file and creates an Envoy container, receiving the port and DNS host record:

locals {
  config_file_path = "/etc/proxy.yaml"
  envoy_config = templatefile("${path.module}/config.tmpl", {
    host_record = var.host_record
    port        = var.port
  })
  echo_config_cmd = "echo '${local.envoy_config}' > ${local.config_file_path}"
  envoy_cmd       = "/usr/local/bin/envoy -c ${local.config_file_path}"
}

resource "azurerm_container_group" "this" {
  name                = "aci-${var.deployment_name}"
  location            = var.location
  resource_group_name = var.resource_group_name
  ip_address_type     = "private"
  network_profile_id  = var.network_profile_id
  os_type             = "Linux"

  container {
    name   = var.deployment_name
    image  = "envoyproxy/envoy:v1.16-latest"
    cpu    = "0.5"
    memory = "1.5"
    commands = [
      "sh",
      "-c",
      "${local.echo_config_cmd} && ${local.envoy_cmd}"
    ]

    ports {
      port     = var.port
      protocol = "TCP"
    }
  }
}

Then the root Terraform script can call the above module when deploying the entire solution, which includes (using a few additional module which are also included in the example):

A private network
Two subnets, for the containers and one for the firewall
A private DNS zone
Three generic backend containers (using Microsoft’s demo container: mcr.microsoft.com/azuredocs/aci-helloworld)
One Envoy container

provider "azurerm" {
  version = "=2.20.0"

  features {}
}

locals {
  deployment_name   = "envoylb"
  location          = "eastus"
  zone_name         = "example.com"
  nodes_record_name = "nodes"
}

# Create resource group
resource "azurerm_resource_group" "this" {
  name     = "rg-${local.deployment_name}-${local.location}"
  location = local.location
}

# Create containers virtual network resources
resource "azurerm_virtual_network" "this" {
  name                = "vnet-${local.deployment_name}-in"
  location            = local.location
  resource_group_name = azurerm_resource_group.this.name
  address_space       = ["10.0.1.0/24", "10.0.2.0/24"]
}

resource "azurerm_subnet" "internal" {
  name                 = "snet-${local.deployment_name}-in"
  resource_group_name  = azurerm_resource_group.this.name
  address_prefixes     = ["10.0.1.0/24"]
  virtual_network_name = azurerm_virtual_network.this.name
  service_endpoints    = ["Microsoft.Storage"]

  delegation {
    name = "snet-delegation-${local.deployment_name}"

    service_delegation {
      name    = "Microsoft.ContainerInstance/containerGroups"
      actions = ["Microsoft.Network/virtualNetworks/subnets/action"]
    }
  }
}

resource "azurerm_subnet" "external" {
  name                 = "AzureFirewallSubnet"
  resource_group_name  = azurerm_resource_group.this.name
  address_prefixes     = ["10.0.2.0/24"]
  virtual_network_name = azurerm_virtual_network.this.name
}

resource "azurerm_network_profile" "this" {
  name                = "np-${local.deployment_name}"
  location            = local.location
  resource_group_name = azurerm_resource_group.this.name

  container_network_interface {
    name = "nic-${local.deployment_name}"

    ip_configuration {
      name      = "ipc-${local.deployment_name}"
      subnet_id = azurerm_subnet.internal.id
    }
  }
}

# Create private DNS zone
resource "azurerm_private_dns_zone" "this" {
  name                = local.zone_name
  resource_group_name = azurerm_resource_group.this.name
}

resource "azurerm_private_dns_zone_virtual_network_link" "this" {
  name                  = "dns-link"
  resource_group_name   = azurerm_resource_group.this.name
  private_dns_zone_name = azurerm_private_dns_zone.this.name
  virtual_network_id    = azurerm_virtual_network.this.id
}

# Create load balanced containers
module "generic_container" {
  source = "./modules/generic-container"

  deployment_name     = "${local.deployment_name}-node"
  resource_group_name = azurerm_resource_group.this.name
  location            = local.location
  nodes_count         = 3
  network_profile_id  = azurerm_network_profile.this.id
  image               = "mcr.microsoft.com/azuredocs/aci-helloworld"
  port                = 80
}

# Create node A DNS record
resource "azurerm_private_dns_a_record" "this" {
  name                = local.nodes_record_name
  zone_name           = local.zone_name
  resource_group_name = azurerm_resource_group.this.name
  ttl                 = 300
  records             = module.generic_container.this_ips
}

# Create envoy container
module "envoy_container" {
  source = "./modules/envoy-container"

  deployment_name     = "${local.deployment_name}-lb"
  resource_group_name = azurerm_resource_group.this.name
  location            = local.location
  network_profile_id  = azurerm_network_profile.this.id
  host_record         = "${azurerm_private_dns_a_record.this.fqdn}"
  port                = 80
}

# Create firewall
module "firewall" {
  source = "./modules/firewall"

  deployment_name     = "${local.deployment_name}"
  resource_group_name = azurerm_resource_group.this.name
  location            = local.location
  pips_count          = 1
  subnet_id           = azurerm_subnet.external.id
}

# Create firewall rules
module "netowork_rule" {
  source = "./modules/network-rule"

  deployment_name     = "${local.deployment_name}"
  resource_group_name = azurerm_resource_group.this.name
  firewall_name       = module.firewall.this_name
  port                = 80
  ip_addresses        = module.firewall.this_pips
}

module "nat_rule" {
  source = "./modules/nat-rule"

  deployment_name      = "${local.deployment_name}"
  resource_group_name  = azurerm_resource_group.this.name
  firewall_name        = module.firewall.this_name
  port                 = 80
  public_ip_addresses  = module.firewall.this_pips
  private_ip_addresses = [module.envoy_container.this_ip]
}

Deployment Testing

Testing our deployment is fairly easy, we can use a browser to send a few requests to the public IP that was created as part of the deployment process, and afterwards, the backend containers’ logs to see the incoming HTTP requests. A more significant load test can be performed with a tool such as Postman, by creating a request and then running it multiple times using the Runner.

Conclusion

The cloud is constantly evolving, but sometimes we need a temporary solution until a managed service is available, in this case, Azure Load Balancer, so it is very important to track release announcements and update our architecture as needed.
